VersaFrame
Versaframe is an exciting building product ideal for both commercial and residential customers who are looking for a safe, fast and economical solution to their building needs.
The system combines the versatility and reliability of steel, the accuracy of convenience of an entirely pre-fabricated off site production process. Delivering an outstanding high tensile steel product, made up of cold formed pre-fabricated steel studs.
Steel studs are at the heart of the Versaframe system. These compact and light weight building blocks are produced and customized for each job. With a high tensile strength, they are ideal for framing buildings, giving added flexibility that cannot be attained using traditional wooden building materials.
Each stud is custom cut by the Versaframe system, to specifications of design, ensuring an accurate easily assembled end product.
The steel studs are produced pre punched with the necessary holes for assembly and allowances for electrical or plumbing services as specified by the design.
Each component and feature is labelled and referenced to the design automatically by the machine, to ensure that tit can be easily and accurately assembled on site.
Versaframe structures are exceptionally fast to construct with up to 80% of the framing work done off site, offering builders the opportunity to have a cleaner and more efficient construction site.
The galvanized steel will be designed using a profile of 3 ½’’ wide, with the grade of G550 Z275 and detailed in accordance with the “Steel Stud Manufactures Association ICBO ER-4943P Product Technical Information Guide”
GALVSTEEL™ G550 steel is a hot-dipped zinc-coated structural steel with a spangled surface and guaranteed minimum yield strength of 550MPa. Suitable for roll forming to a minimum internal diameter of 4t.
Zinc, or an alloy of zinc and aluminum, are the most common protective coatings used on light gauge steel. ... The specifications Z275 and Z600 refer to the zinc coating, measured in grams of zinc or aluminum/zinc per square meter. This measurement is the total coating mass on both sides of the steel.
How Can I get a quote?
Send your plans to customerservice@caribbeanmetalslimited.com
What wind speed can the system be designed too?
The system can be designed to wind speeds between 130- 170mph.
What is the makes the system?
The system is basically galvanized stud and tracks.
Does the cost include all fasteners?
Yes, all fasteners are supplied.
Can the frame be bolted to a wooden floor?
No, this system is designed to be bolted on to a concrete floor.
Can the system design a with two floor house?
Yes, the system can be designed up to 2 floors.
